Two Stroke Mods.......

Squish band thickness is the distance between the piston and the cylinder head where the piston meets the cylinder bore. If the squish clearance and width is set to an optimal amount, then the fuel is burned efficiently. If the squish distance is too great then the fuel in the squish band is not burned and the engine runs very “dirty”. It is inefficient and does not produce optimal power.
The squish band is a very important part of head mods and this is where I spend alot of time. Just getting the proper squish band without going overboard on the compression will give great results - Delivering “HORSEPOWER” and “RELIABILITY”
Head modification is more than just raising compression. It is a way to help your engine breath, burn more of the available fuel, and help cool. All of this will give you better snap, rev and torque with great reliability.



Introduction


If the squish band thickness is not optimal, the cylinder head can be machined to correct this clearance. After the new squish clearance is achieved the head is then cc’ed and the combustion chamber is re-machined to the desired compression to meet the owner’s needs. It is also necessary for the owner to provide an accurate baseline compression measurement. The head is then machined to set proper squish and the combustion chamber is reshaped to provide the desired amount of compression.

Overall compression and compression ratios are typically set up for proper operation at sea level. Low air densities at higher altitudes will, in turn, lead to low compression readings. If the bike’s owner knows that they will not venture to lower altitudes - the head can be machined to provide appropriate compression for their altitude range.

Compression can be “set” higher if the rider wishes to use race fuel. It should be noted that increasing compression will shift power lower in the power band - giving up top end power along the way (all other things equal). So “more” isn’t always better, it depends on what you wish to achieve.

Read and understand the following before measuring squish

These test solders are my only link into your engine so that I know what needs to be done without actually having the engine in front of me. So, it is very important that you pay close attention to the process and do the solder tests with great care. Your head will be modified using these solders that you have provided me.

As you can see in the example pic below, the solder lays flat across the top of the piston with a small "camel hump" that also lays flat on the piston. The reason for the small hump is to allow you to either pull the ends farther apart or push the ends closer together, to get the ends of the solder to rub on the cylinder wall. The hump of the solder is to lay flat on top of the piston also, this will keep the solder from moving around (you can put a small dab of grease on the hump to help hold it in place).

It is also very important that the hump shape of the solder does not come in contact with the squish band area.

One last note before you go on to the actual Measuring Squish , make sure that the ends of the solder touch the cylinder wall on both sides and that both ends are cut blunt and clean. Again I can not stress enough the importance of the solder tests, send at least 2 to 3 tests, they are easy to do.

Measuring Squish

The best and easiest way to measure the squish is by using a piece of rosin-core-solder. You can buy this from local hardware stores or places like radio shack. The solder needs to be thick enough to smash slightly but not so thick as to bind the engine. After you do it a few times, you will get the hang of it.

On the stock GasGas head the clearance is usually around .090+” so this means you will need your piece of solder to be 3/32” or .093” to .125”, If you can not find 3/32” rosin-core-solder, try and find 1/8” rosin-core or acid-core solder. DO NOT use solder such as the types used for plumbing.

You will need to remove the head and remove the flywheel side cover so that you can access the flywheel nut to rotate the crankshaft (in most cases you can rotate the flywheel by hand) Do Not use the kick starter. Now rotate until the piston is about 1/4” to 3/8” below top dead center (TDC).

You will then need to bend the solder into a shape shown in photo 1. The solder needs to lay right across the center line of the piston pin. Make sure the ends of the solder touches the bore of the cylinder on both sides. You can use a small dab of grease on the hump shape that should be laying flat on the top of the piston.




Solder in cylinder


Next install the head and snug it down with the head nuts. Note that you do not need to install the o-ring during this process. DO NOT use the kickstarter to rotate the engine. Remove the spark plug. Using a wrench on the crankshaft nut carefully turn the crank shaft rotating the piston over TDC, you will feel a slight bind and this is normal. Keep the piston near TDC throughout the process. There is absolutely no need to move the piston any lower than 1/4" below TDC. Do not allow the piston to pass below the ports. Slowly rotate back and forth through TDC a couple of times couple of times and then remove the head.

You will see where the solder was smashed and this is your current squish band clearance. It can be measured with calipers. You will need to send this to me with the head so I can re-cut your head for a closer clearance.

Hope this helps, oh and by the way you may want to smash several pieces of solder and send them all. NOTE!!!!! You must use Rosin Core or acid core Solder not solid or plumbing solder (solid core will not smash as well, and the reading will not be correct as there will be a preload that won’t measure).


About the Author :

Ron Black of RB-Designs has been building race engines of all kinds and his own custom race parts since 1970. He gained experience working side by side with many “old school engineers”. He has built 3 dyno's and has been running them since the early 70's. He has one of these dynos in his shop.

Over the years, he designed a number of motorcycle service departments and managed many of these. He designed his brother’s shop and worked with him for about 12 years prior to starting his own shop 10 years ago.

He has worked with both the Yamaha Road Racing Team and with Kawasaki’s motocross R&D department. He has spent the majority of his life designing reliable high performance parts.

Courtesy:-
www.gasgasrider.org
By Ron Black of RB-Designs

Thursday, December 10, 2009

Oils.

The primary objective of the lubricant is reduction of friction caused between moving parts of engine. This in turn helps to increase life of the engine. Specialized lubricants such as hydraulic or transmission oils perform additional functions. Lubricants are also used as coolants, to reduce the heat that is produced by the engine.
Reduces Friction ________________________________________________________________
This result in reduction of energy required to operate the mechanism and also reduces local heat generation. It forms a fluid film that keeps one moving surface out of direct contact with the opposing surface.
Reduces Wear & Tear ____________________________________________________________
Additives in the lubricants lay down a chemical film that protects wear and tear. Oil additives that reduce friction contribute to the energy efficiency of the vehicle.
Cooling of Engine _______________________________________________________________
Lubricants work as an initial heat transfer agent in engine between some parts heated by combustion and the heat dissipating systems. Lubricants reduce heat generated by friction or the mechanical work performed. Circulation of the lubricant transfer heat away from hot surfaces, warms cold surfaces, and transports debris and contaminants to the filter.
Anti-corrosion __________________________________________________________________
Oil can become acidic and corrode metals because of its own degradation or by combustion contamination. Moist environments and lack of use can also cause rusting. Lubricants act as anti-corrosion agents and prevent any degradation.
Cleaning _______________________________________________________________________
Deposits such as “solid carbon”, “varnish”, or “sludge” can interfere with the correct and efficient operation of the equipment. Piston rings may become stuck and oil passages get blocked. Lubricants can prevent this by improving viscosity control of oils.
Sealing ________________________________________________________________________
Lubricants assist in forming seals between pistons and cylinders. High-quality oils can provide increased bearing protection.
Help Save Costs ________________________________________________________________
Good quality lubricants reduces drain interval of oil which leads to savings of costs in terms of material, labor and equipment downtime.
DIFFERENT GRADES OF OIL
Choosing the proper viscosity grade for the ambient temperature of your geographic location becomes vitally important.
To lubricate and provide protection to the engine and improving its performance, the viscosity (the measure of the Oil’s thickness or resistance to flow) of the engine oil should be capable of holding up the engine’s extreme temperature conditions. Oil thins when heated and thickens when cooled.
There are mono-grade oils whose viscosity is defined at only one temperature, either high or low. A multi-grade meets both high and low temperature viscosity requirements simultaneously. These are easily recognized by dual viscosity designations like 15W40, 10W30 etc. For instance in case of 15W40, 15W is the low temperature designation and the 40 is the high temperature designation.
It is the viscosity modifier additive that produces a thickening effect at high temperatures but is dormant at low temperatures.
CHOOSING THE RIGHT GRADE
The vehicle handbook generally specifies the right grade of oil for the car under specific environmental conditions

Viscosity Grade Temperature Conditions Descriptions
5W-30 Below 0°F Mostly used in the ultra modern automobile models
Excellent fuel economy
Low temperature performance

--------------------------------------------------------------------------------

10W-30 Above 0°F Most frequently recommended for most automobile
engines like high-performance multi-valve engines
and turbo-charged engines

--------------------------------------------------------------------------------

10W-40 Above 0°F For controlling engine wear and tear
For preventing oil breakdown from oxidation

--------------------------------------------------------------------------------

20W-50 Above 20°F For maximum protection for high-performance, high-
RPM racing engines.
Very good choice for high temperature and heavy
loads, e.g. driving in the desert or towing a trailer
at high speeds for long periods.

--------------------------------------------------------------------------------

SAE 30 Above 40°F For cars and light trucks

--------------------------------------------------------------------------------

SAE 40 Above 60°F Not recommended when cold-temperature starting
is required

--------------------------------------------------------------------------------



Courtesy:- http://www.tidewaterindia.com

Apology

Due to technical problem, unable to upload second part of Honda EC U controlled ABS system
